Honda Odyssey V (2013-2017) cabin accessories system Wiring diagram
This page shows the only wiring diagram for the component.cabin accessories system, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cabin accessories system (1 of 1)
B-CAN HI
B-CAN LO
BACKUP
BLK WIRE
BLU WIRE
BUZZER
CABIN ACCESSORIES SYSTEM
CARGO LT-
COMPUTER DATA LINES SYSTEM
DOOR LOCK RD RLY CL-
DOOR LOCKS SYSTEM
DOOR UNLOCK RD RLY CL-
FUEL LID OPEN RLY
FUEL LID SW RLY
FUSE 13
FUSE 16
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
PTG FULL
RA DOOR SW
RA SIL UL SW+
RD DOOR SW
RD SIL L SW+
RD SIL UL SW+
REAR FUSE BOX (BEHIND LEFT REAR SIDE TRIM PANEL)
REAR MICU
RED WIRE
RIGHT END OF DASH)
RR WIPER AS
RR WIPER RLY CL-
T GATE HANDLE SW+
T GATE SW+
T/G (TRUNK) ACT RLY CL-
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDER-HOOD FUSE/RELAY BOX
VAC ON IND
VAC RELAY
VAC SW
VAC TIME IND
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (2 of 2) -> CABIN ACCESSORIES SYSTEM
