Honda Odyssey V (2013-2017) bsn sw Wiring diagram
This page shows the only wiring diagram for the component.bsn sw, which is found in the car Honda Odyssey V (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bsn sw (1 of 1)
+B RADIO
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
BSM CAM +B
BSM CAM SH
BSM CAM V GND
BSM CAMM VID
BSN SW
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 15
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LANE WATCH CAMERA
LANE WATCH CAMERA SWITCH
LWC
LWC LWC VID
LWC SH
LWC VCC
LWC VID
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT POWER MIRROR
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Lane watch camera circuit -> BSN SW
