Honda Odyssey V (2013-2017) +b back up Wiring diagrams

This page contains all the electrical diagrams for the component. +b back up, in which he is found in the car Honda Odyssey V (2013-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram +b back up (1 of 4)

Wiring diagram +b back up for Honda Odyssey V (2013-2017) (1 of 4)

Get access

+B BACK UP ATP-P ATPP B-CAN HI B-CAN LO B-CANL BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S MICU DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR/POSITION SENSOR DRIVER'S POWER SEAT RECLINE MOTOR/POSITION SENSOR DRIVER'S UNDER-DASH FUSE/RELAY BOX FHDN FHM - FHSE FHUP FUSE 11 FUSE 15 FUSE 16 FUSE 19 FUSE 32 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE POWER MIRROR CONTROL UNIT POWER SEAT CONTROL UNIT PPL REBW PNK RHUP WIRE RED WIRE REFW REM - PNK RHM - WIRE REM+ RESE RHDN RHM (+) PNK WIRE RHSE RIGHT END OF DASH) SCOM PNK B-CANH WIRE SEG SENSOR SLBW SLFW SLM + PPL FHM + SLM - SLSE SVCC UART UNDER-HOOD FUSE/RELAY BOX VBU WHT WIRE YEL WIRE

Go to component -> Memory seat circuit (1 of 3) -> +B BACK UP

Wiring diagram +b back up (2 of 4)

Wiring diagram +b back up for Honda Odyssey V (2013-2017) (2 of 4)

Get access

+B BACK UP AUDIO AUX DET AUDIO AUX SH AUDIO IN GND AUDIO IN R AUDIO IN SH AUDIO-IN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 16 GA SYS ON GA-BUS SH GA-BUS- GRN WIRE GRY WIRE HOT AT ALL TIMES HP L HP L OUT HP R HP R OUT HP R/L GND HP R/L OUT GND HP R/L OUT SH ILLUMI (-) ILLUMI- (LED) LT BLU WIRE ORG/ WIRE PNK WIRE RADIO CIRCUIT REAR CONTROLLER, SCREEN RED WIRE RES AUXILIARY JACK ASSEMBLY RR AUX AUDIO GND RR AUX AUDIO L RR AUX AUDIO R RR NTSC RR NTSC GND UNDER-HOOD FUSE/RELAY BOX VIDEO GND VIDEO SH VIDEO+ WHT WIRE YEL WIRE

Go to component -> Rear seat entertainment circuit, w/ navigation & res wide (1 of 3) -> +B BACK UP
