Car Wiring Diagrams for Automatic day/night mirror circuit for Honda Odyssey IV (2008-2013)

1 2 3 4 5 6 7 (CONTROL UNIT BUILT-IN) A/T REVERSE DIODE A A/T REVERSE DIODE B A/T REVERSE RELAY AUDIO-NAVIGATION UNIT (W/ NAVIGATION) AUTOMATIC DIMMING INSIDE MIRROR AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR (OPTION CONNECTOR) BACK LT GND BACK LT- BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 1 DRIVER'S JUNCTION BOX 1 (LEFT SIDE OF DASH) DRIVER'S MICU DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) EXCEPT HONDA ACCESSORY F-CAN-H F-CAN-L ATPR FUSE 11 FUSE 26 GRY WIRE HONDA ACCESSORY HOT IN ON HOT IN ON OR START LT GRN WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM WHT WIRE YEL WIRE
