Hands free module circuit, without navigation for Honda Odyssey IV (2008-2013)
Hands free module circuit, without navigation (1 of 2)
20 21 22 5 3 4 2 19 GA BUS + GA BUS - GA BUS SH
AUDIO DISPLAY USB ADAPTER CONTROL UNIT
BLK WIRE
BLU WIRE
BLUETOOTH TRANSCEIVER
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY
FUSE 13 BOX (LEFT END OF DASH)
FUSE 15
GA BUS - GA BUS + HFL MUTE HFL STRG SW GND
GRY WIRE
HANDSFREELINK CONTROL UNIT (CENTER OF DASH)
HOT AT ALL TIMES
HOT IN ACC OR ON
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PPL
PPL PPL GA AUDIO L+ GA AUDIO L- GA AUDIO R+ GA AUDIO R-
PPL/ PPL/ PPL/
TELM SIG SH TELM SIG - GA AUDIO L- GA AUDIO R-
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
W/ REAR ENTERTAINMENT SYSTEM W/O REAR ENTERTAINMENT SYSTEM
XM RECEIVER (BASE OF RIGHT "D" PILLAR)
YEL WIRE
Hands free module circuit, without navigation (2 of 2)
1 2 3 4 5 6 7 +B PPL
AUDIO REMOTE SWITCH
AUDIO UNIT
BACK SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (IN STEERING WHEEL)
FRONT HFL-NAVIGATION ANC MICROPHONE (CENTER ROOF CONSOLE)
GA AUDIO SH GA AUDIO L+ GA AUDIO L- GA AUDIO R+ GA AUDIO R- PPL
GRY WIRE
HANG UP SWITCH
HFL MUTE
HFL SWITCH STEERING WHEEL
JUNCTION
LT BLU WIRE
LT GRN WIRE
MC + MC - GND
ORG/ WIRE
PICK-UP SWITCH
PPL
PPL/ PPL/ PPL/
PPL/ PPL/ PPL/ PPL/
TALK SWITCH
TELM SIG SH TELM SIG + TELM SIG - REMOTE GND GA BUS + GA BUS - GA BUS SH
WHT WIRE
YEL WIRE
