Honda Odyssey IV (2008-2013) control circuit Wiring diagrams
This page contains all the electrical diagrams for the component. control circuit, in which he is found in the car Honda Odyssey IV (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram control circuit (1 of 3)
BOX (RIGHT SIDE OF DASH)
BOX 1 (LEFT SIDE OF DASH)
BRN WIRE
BUS BAR
CENTER JUNCTION
CONTROL CIRCUIT
CONTROL CIRCUIT BOARD SML RLY CL-
DRIVER'S FOOTWELL LIGHT
DRIVER'S JUNCTION
DRIVER'S JUNCTION BOX 2 (LEFT SIDE OF DASH)
FRONT PASSENGER'S FOOTWELL LIGHT
FUSE 22
FUSE 25
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION KEY
IGNITION KEY LIGHT
KICK PANEL)
LIGHT) (RIGHT SIDE OF STEERING COLUMN) SWITCH
LT BLU WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT
PNK 6 WIRE
PNK PPL WIRE
PNK WIRE
RED WIRE
RELAY CONTROL MODULE
STEERING LOCK (IGNITION KEY SWITCH/KEY
TAILLIGHT RELAY
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
W/ MEMORY
W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 4) -> CONTROL CIRCUIT
Wiring diagram control circuit (2 of 3)
1 2 (OPTIONAL CONNECTOR) PNK (REMOTE STA- RTING SYSTEM) WIRE
30 28 36 19 18 20 B-CAN LO B-CAN HI UART PNK PNK WIRE
B-CAN
B-CAN B-CAN HI LOW
B-CAN B-CAN LOW HI
B-CAN LOW
B-CAN LOW HI
BCAN-HI
BCAN-LO
BLK WIRE
BLU WIRE
BSI CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
CONTROL CIRCUIT
CONTROL CIRCUIT BOARD
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S JUNCTION BOX 1 (LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2 (LEFT SIDE W/ OF DASH) MEMORY
DRIVER'S MICU
DRIVER'S UNDER-DASH B-CAN FUSE/RELAY HI BOX (LEFT END OF DASH)
F-CAN HI
F-CAN LO
GAUGE CONTROL MODULE
GRY WIRE
ORG/ WIRE
PNK 26 28 B-CAN HI B-CAN LO MANUAL A/C WIRE
PNK 5 6 7 8 WIRE
PNK AUTOMATIC A/C B-CAN HI B-CAN LO WIRE
PNK BLU WIRE
PNK CLIMATE CONTROL UNIT WIRE
PNK PNK 2 3 4 WIRE
PNK WIRE
POWER TAILGATE CONTROL UNIT (IF EQUIPPED) (BEHIND LEFT REAR SIDE TRIM PANEL)
POWER WINDOW MASTER SWITCH
REAR MICU
RELAY CONTROL MODULE
TRANSCEIVER F-CAN
TRANSCEIVER/
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
W/ BSI SYSTEM
W/ HVAC CONTROAL UNIT MEMORY
W/O BSI SYSTEM
W/O MEMORY
WHT WIRE
YAW RATE- ACCELERATION SENSOR (CENTER OF DASH)
Go to component -> F-can & b-can circuit (1 of 2) -> CONTROL CIRCUIT
Wiring diagram control circuit (3 of 3)
5-SPEED A/T 6-SPEED A/T
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 11
FUSE 28
FUSE 8
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICM
IGNITION COIL RELAY
IGNITION COILS (1, 2, 3: RIGHT SIDE OF ENGINE) (4, 5, 6: LEFT SIDE OF ENGINE)
LT BLU WIRE
LT GRN WIRE
MIL IND
ORG/ WIRE
PGM-FI SUB- RELAY
PNK WIRE
PPL
RADI- ATOR FAN RELAY
REAR ROCKER ARM OIL PRESSURE SWITCH (REAR OF RIGHT CYLINDER BANK)
RED WIRE
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l (4 of 7) -> CONTROL CIRCUIT
