Honda Odyssey IV (2008-2013) camera video Wiring diagram
This page shows the only wiring diagram for the component.camera video, which is found in the car Honda Odyssey IV (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera video (1 of 1)
AUDIO DISPLAY USB ADAPTER CONTROL UNIT
B(+)
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA
CAMERA ADPT
CAMERA BIT 0
CAMERA BIT 1
CAMERA SH
CAMERA V GND
CAMERA VCC
CAMERA VIDEO
FUSE
GND (RC)
GND VIDEO (RC) GND
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
NAVIGATION DISPLAY UNIT
ORG/ WIRE
PARK AID DET
PART AID DET
REARVIEW CAMERA (RIGHT SIDE OF TAILGATE)
RED WIRE
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
VIDEO+
W/ NAVIGATION
W/ PARKING, BACKUP SENSOR SYSTEM
W/ POWER TAILGATE
W/O NAVIGATION
W/O POWER TAILGATE
WHT WIRE
YEL WIRE
Go to component -> Rear camera circuit -> CAMERA VIDEO
