Car Wiring Diagrams for Headlights circuit, touring with drl for Honda Odyssey III (2003-2008)

AREA NETWORK CONTROLLER POWER SUPPLY CIRCUIT/CONTROLLER AUTOMATIC LIGHTING CONTROL UNIT (UNDER LEFT SIDE OF DASH) AUTOMATIC LIGHTING SENSOR AUTOMATIC LIGHTING SENSOR/SUNLIGHT SENSOR (TOP OF DASH) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN/YEL WIRE COMBINATION SWITCH CONTROL UNIT DAY LT MICU GND SG-1 PG DRIVE CIRCUIT DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) DRL INDICATOR FUSE 21 FUSE 3 FUSE 7 FUSE 30 GAUGE CONTROL MODULE HIGH BEAM INDICATOR HOT AT ALL TIMES HOT IN ON HOT IN ON OR START LT BLU/WHT WIRE LT GRN WIRE MICU PASSENGER'S UNDER-DASH FUSE/RELAY BOX (UNDER RIGHT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE VBU BUS WARNING DRIVE CIRCUIT WHT WIRE WHT/RED WIRE WIPER/WASHER SWITCH YEL WIRE

AUXILIARY UNDER-HOOD FUSE RELAY (RIGHT REAR OF ENGINE COMPT) BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CONTROL BLOCK DIMMER SWITCH 0) LOW 1) HIGH 2) PASSING DRL RELAY ELD UNIT FOG LIGHT RELAY (RIGHT FOG LIGHT SWITCH FUSE 1 FUSE 3 FUSE 5 FUSE 6 FUSE 7 HEADLIGHT SWITCH 0) OFF 1) HI BEAM 2) AUTO 3) LO BEAM COMBINATION LIGHT SWITCH HI LO HIGH BEAM HEADLIGHT RELAY HOT AT ALL TIMES LEFT FOG LIGHT LEFT HEADLIGHT LOW BEAM HEADLIGHT RELAY LT BLU/WHT WIRE LT GRN WIRE MULTI- FUSE 22 RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY CONTROL MODULE RIGHT FOG LIGHT RIGHT HEADLIGHT UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/GRN WIRE WHT/RED WIRE
