Back-up lamps circuit for Honda Odyssey III (2003-2008)
Back-up lamps circuit
ATP-R
BACK LT-
BLK WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
FUSE 21
GRN WIRE
HOT IN ON OR START
JUNCTION CONNECTOR
LEFT BACK-UP LIGHT
MICU
MICU-REAR JUNCTION BOX (AT RIGHT "D" PILLAR)
PCM (RIGHT SIDE OF ENGINE COMPT)
RED WIRE
RIGHT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSAXLE END COVER)
WHT WIRE
