Honda Odyssey III (2003-2008) right corner back-up sensor Wiring diagram
This page shows the only wiring diagram for the component.right corner back-up sensor, which is found in the car Honda Odyssey III (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right corner back-up sensor (1 of 1)
BACK LT-
BACK-UP SENSOR BEEPER ASSEMBLY (RIGHT REAR OF VEHICLE)
BACK-UP SENSOR BEEPER SWITCH (LEFT "D" PILLAR)
BACK-UP SENSOR CONTROL UNIT (LEFT REAR OF VEHICLE)
BACK-UP SENSOR IN-LINE FUSE (LEFT REAR OF VEHICLE)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
FUSE 21
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT IN ON OR START
LEFT CORNER BACK-UP SENSOR
LEFT MIDDLE BACK-UP SENSOR
MICU
MICU- REAR JUNCTION BOX (BEHIND RIGHT (NOT REAR SIDE TRIM PANEL) USED)
ON INDICATOR
ORG/ WIRE
ORG/RED WIRE
RED WIRE
RIGHT CORNER BACK-UP SENSOR
RIGHT MIDDLE BACK-UP SENSOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Parking assistant circuit, except touring -> RIGHT CORNER BACK-UP SENSOR
