Honda Odyssey III (2003-2008) pnk ccsam Wiring diagrams
This page contains all the electrical diagrams for the component. pnk ccsam, in which he is found in the car Honda Odyssey III (2003-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk ccsam (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ANC RR+ ANC FR+
10 11 12 13 PPL
ACTIVE NOISE CONTROL UNIT (BEHIND MIDDLE OF DASH)
ANC CHK
ANC RR- ANC FR-
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT) FUSE 5
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
CABLE REEL
CHANNEL DOWN SWITCH
CHANNEL UP SWITCH
DRIVER'S DOOR SPEAKER
FL PRE IN SH
FL PRE IN+
FR L SPKR-
FR L TW-
FR PRE IN SH
FR PRE IN-
FR R SPKR-
FR R TW-
FRONT PASSENGER'S DOOR SPEAKER
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
JUNCTION CONNECTOR
LEFT REAR DOOR SPEAKER PPL
LEFT TWEETER
LT BLU WIRE
MODE SWITCH
NAVIGATION SYSTEM
NEP CCSAM PNK WIRE
PNK CCSAM NEP INTR LT- WIRE
PNK CCSAM WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RADIO REMOTE SWITCH
RADIO SW +B
RED WIRE
RED/BLU WIRE
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
RL PRE IN SH
RL PRE IN-
RR L SPKR-
RR PRE IN SH
RR PRE IN-
RR R SPKR-
STEERING WHEEL)
STEREO AMPLIFER
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
WHT/GRN WIRE
WOOFER
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, touring with navigation (2 of 2) -> PNK CCSAM WIRE
