Power window circuit for Honda Odyssey II (1999-2003)

Power window circuit (1 of 2)

Odyssey Honda II (1999-2003): Power window circuit (1 of 2)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE DOOR MULTIPLEX CONTROL UNIT (IN DRIVER'S DOOR) DRIVER'S SWITCH DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) DRIVER'S WINDOW MOTOR PULSER FRONT PASSENGER'S DOOR SWITCH FRT PASS CTRL FRT PASS CTRL COMMUN LINE RR WIN CTRL RR WIN CTRL FRT PASS DR FUSE 13 FUSE 15 FUSE 16 FUSE 7 FUSE 8 FUSE 9 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGN INPUT BATTERY INPUT GROUND LEFT REAR SWITCH MAIN SWITCH PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH FUSE/RELAY BOX PNK WIRE POWER WINDOW IMMERSION CIRCUIT POWER WINDOW RELAY RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT SWITCH RIGHT REAR SWITCH WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

Power window circuit (2 of 2)

Odyssey Honda II (1999-2003): Power window circuit (2 of 2)

Get access

2 4 (2000) (2001) 4 6 (2000) (2001) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE DRIVER'S DOOR SWITCH DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FRONT PASSENGER'S WINDOW MOTOR FRONT PASSENGER'S WINDOW SWITCH 1 = DOWN 2 = UP FUSE 13 FUSE 9 GRN WIRE GRN/RED WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT REAR POWER QUARTER WINDOW CLOSE RELAY LEFT REAR POWER QUARTER WINDOW MOTOR LEFT REAR POWER QUARTER WINDOW OPEN RELAY ORG/ WIRE PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR POWER QUARTER WINDOW CLOSE RELAY RIGHT REAR POWER QUARTER WINDOW MOTOR RIGHT REAR POWER QUARTER WINDOW OPEN RELAY WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE
