Power door lock circuit, lx without keyless entry for Honda Odyssey II (1999-2003)

Power door lock circuit, lx without keyless entry (1 of 2)

Odyssey Honda II (1999-2003): Power door lock circuit, lx without keyless entry (1 of 2)

Get access

BATTERY IN BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE COMM LINE COMM LINE BATTERY INPUT KEY IN IGN INPUT COMM LINE GROUND DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FRONT PASSENGER'S DOOR KEY CYLINDER SWITCH FRONT PASSENGER'S DOOR LOCK SWITCH FUSE 12 FUSE 13 FUSE 9 GROUND HOT AT ALL TIMES HOT IN ON OR START IGN INPUT IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT LOCK ORG/ WIRE PASS KEY SW PASS LCK SW PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE UNLOCK WHT/RED WIRE WHT/YEL WIRE YEL WIRE

Power door lock circuit, lx without keyless entry (2 of 2)

Odyssey Honda II (1999-2003): Power door lock circuit, lx without keyless entry (2 of 2)

Get access

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DOOR MULTIPLEX CONTROL UNIT (IN DRIVER'S DOOR) DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FRONT PASSENGER'S DOOR LOCK ACTUATOR FUEL FILL DOOR RELAY FUEL FILL DOOR SWITCH FUSE 12 GRN WIRE GRN/RED WIRE HOT AT ALL TIMES LEFT JUNCTION SWITCH LEFT SLIDING DOOR LOCK KNOB SWITCH/ACTUATOR LOCK LT GRN/RED WIRE PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE RIGHT JUNCTION SWITCH RIGHT SLIDING DOOR LOCK ACTUATOR SLIDING DOOR LOCK CONTROL UNIT (IN LEFT SLIDING DOOR) TAILGATE LOCK ACTUATOR TAILGATE LOCK KEY CYLINDER SWITCH UNLOCK WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL/RED WIRE
