Car Wiring Diagrams for Entry light timer circuit for Honda Odyssey II (1999-2003)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU/WHT WIRE BOX (RIGHT SIDE OF ENGINE COMPARTMENT) BRN WIRE CARGO AREA LIGHT DOOR MULTIPLEX CONTROL UNIT DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR SWITCH DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FRONT INDIVIDUAL MAP LIGHT FUSE 11 FUSE 47 FUSE 9 FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HOME LINK UNIT HOT AT ALL TIMES HOT IN ON OR START HOT W/ HEADLIGHT SWITCH IN PARK OR HEAD IGNITION KEY LIGHT IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT INTERIOR LIGHTS RELAY (BEHIND LEFT SIDE OF DASH) INTERIOR LIGHTS SWITCH LEFT LEFT MIDDLE INDIVIDUAL MAP LIGHT LEFT REAR INDIVIDUAL MAP LIGHT LEFT SLIDING DOOR SWITCH LT GRN WIRE PASSENGER'S MULTIPLEX CONTROL UNIT PASSENGER'S UNDERDASH PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE RED/BLK WIRE RIGHT RIGHT MIDDLE INDIVIDUAL MAP LIGHT RIGHT REAR INDIVIDUAL MAP LIGHT RIGHT SLIDING DOOR SWITCH FRONT PASSENGER'S DOOR SWITCH STEERING LOCK TAILLIGHT RELAY (BEHIND LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE
