Immobilizer circuit for Honda Odyssey II (1999-2003)

Immobilizer circuit

Get access

1999-00 BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE DRIVER'S UNDERDASH FUSE/RELAY BOX DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH) FUEL PUMP FUEL TANK UNIT FUSE 1 FUSE 13 FUSE 46 GAUGE ASSEMBLY IMMOBILIZER INDICATOR LIGHT GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN HOT IN ON OR START IMMOB LT CTRL IMMOB ENABLE FUEL PUMP CTRL IMMOB CODE IN IMMOBILIZER RECEIVER UNIT (ON STEERING COLUMN) ORG/ WIRE ORG/BLU WIRE PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PGM-FI MAIN RELAY (BEHIND LEFT SIDE OF DASH) PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND LOWER CENTER OF DASH) PWR INPUT PWR INPUT GROUND RED WIRE RED/WHT WIRE UNDERHOOD FUSE/ RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
