Honda Odyssey II (1999-2003) ground battery input Wiring diagrams
This page contains all the electrical diagrams for the component. ground battery input, in which he is found in the car Honda Odyssey II (1999-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ground battery input (1 of 2)
BATTERY IN
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
COMM LINE
DR LCK SW
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S UNDERDASH FUSE/RELAY BOX (BELOW LEFT END OF DASH)
FRONT PASSENGER'S DOOR SWITCH
FUSE 12
FUSE 13
FUSE 9
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GROUND BATTERY INPUT
GRY WIRE
HOOD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGN INPUT
IGNITION INPUT LT SLID DR CTRL RT SLID DR CTRL LOCK UNLOCK PANIC BATTERY INPUT
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
KEY CYL SW
KEYLESS RECEIVER UNIT (BEHIND RIGHT END OF DASH)
LCK KNOB SW
LEFT POWER SLIDING DOOR CONTROL UNIT
LEFT SLIDING DOOR SWITCH
LOCK
LT SLID DR CTRL RT SLID DR CTRL
ORG/ WIRE
PANIC
PASS DR SW
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PNK/BLU WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT POWER SLIDING DOOR CONTROL UNIT
RIGHT SLIDING DOOR SWITCH
SLID DR SW
TAILLIGHT RELAY (BEHIND LEFT SIDE OF DASH) COMBINATION LIGHT SWITCH
TRANSMITTER
UNLOCK
WHT/YEL WIRE
YEL WIRE
Go to component -> Anti-theft circuit, ex (1 of 3) -> GROUND BATTERY INPUT
