Car Wiring Diagrams for Instrument illumination circuit, lx for Honda Odyssey I (2004-2009)

A/C CONTROL PANEL A/T GEAR POSITION CONSOLE LIGHT AUDIO UNIT B-CAN BLK WIRE BLK/RED WIRE BLU WIRE BRIGHTENING SWITCH BRN WIRE BRN/YEL WIRE COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT CONTROL BLOCK DASH LIGHTS BRIGHTNESS CONTROLLER DIMMING SWITCH DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 21 FUSE 4 FUSE 7 GAUGE CONTROL MODULE GLOVE BOX LIGHT HAZARD WARNING SWITCH HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD HOT AT ALL TIMES HOT IN ON OR START INTERIOR LIGHT SWITCH LT GRN WIRE MICU MULTI INFORMATION DISPLAY UNIT PASSENGER'S UNDER-DASH FUSE/RELAY BOX (UNDER RIGHT SIDE OF DASH) POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER REAR A/C CONTROL PANEL JUNCTION CONNECTOR RED WIRE RED/BLK WIRE RELAY CONTROL MODULE TAILLIGHT RELAY TRANSCEIVER AREA NETWORK BODY CONTROLLER UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) VBU VSA OFF SWITCH WHT WIRE WHT/RED WIRE WIPER/ WASHER SWITCH YEL WIRE
