Back-up lamps circuit for Honda Odyssey I (2004-2009)
Back-up lamps circuit
ATP-R
AUTOMATIC DIMMING INSIDE MIRROR
BACK LT-
BLK WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
FUSE 21
GRN WIRE
HOT IN ON OR START
JUNCTION CONNECTOR
LEFT BACK-UP LIGHT
MICU
MICU-REAR JUNCTION BOX (BEHIND RIGHT REAR SIDE TRIM PANEL)
NAVIGATION UNIT (NAVIGATION: EX-L, TOURING)
NAVIGATION: EX-L, TOURING, LX, EX, EX-L
PARKING/ BACK-UP SENSOR CONTROL UNIT (UNDER LEFT SIDE OF DASH)
RIGHT BACK-UP LIGHT
TOURING LX, EX, EX-L
TRANSMISSION RANGE SWITCH (ON TRANSAXLE END COVER)
WHT WIRE
