Honda Odyssey I (2004-2009) transceiver area network body controller Wiring diagrams
This page contains all the electrical diagrams for the component. transceiver area network body controller, in which he is found in the car Honda Odyssey I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
transceiver area network body controller wiring diagram (1 of 2)
A/T GEAR POSITION CONSOLE LIGHT
APS SWITCH (TOURING)
B-CAN
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRIGHTENING SWITCH
BRN/YEL WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
CONTROL BLOCK
DASH LIGHTS BRIGHTNESS CONTROLLER
DASH- BOARD POWER TAILGATE SWITCH (TOURING)
DIMMING SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
DRIVING POSITION MEMORY SWITCH (TOURING)
FUSE 21
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GRN/RED WIRE
HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR
LT GRN WIRE
MICU
MOONROOF SWITCH
MULTI INFORMATION DISPLAY UNIT
PARKING/ BACK-UP SENSOR SWITCH (TOURING)
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (UNDER RIGHT SIDE OF DASH)
POWER MIRROR SWITCH
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RED/BLK WIRE
RELAY CONTROL MODULE
TAILLIGHT RELAY
TOURING
TRANSCEIVER AREA NETWORK BODY CONTROLLER
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
VBU
VSA OFF SWITCH
WHT WIRE
WHT/RED WIRE
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Instrument illumination circuit, ex, ex-l, touring (1 of 2) -> TRANSCEIVER AREA NETWORK BODY CONTROLLER
transceiver area network body controller wiring diagram (2 of 2)
A/C CONTROL PANEL
A/T GEAR POSITION CONSOLE LIGHT
AUDIO UNIT
B-CAN
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRIGHTENING SWITCH
BRN WIRE
BRN/YEL WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
CONTROL BLOCK
DASH LIGHTS BRIGHTNESS CONTROLLER
DIMMING SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
FUSE 21
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
HAZARD WARNING SWITCH
HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD
HOT AT ALL TIMES
HOT IN ON OR START
INTERIOR LIGHT SWITCH
LT GRN WIRE
MICU
MULTI INFORMATION DISPLAY UNIT
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (UNDER RIGHT SIDE OF DASH)
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
REAR A/C CONTROL PANEL JUNCTION CONNECTOR
RED WIRE
RED/BLK WIRE
RELAY CONTROL MODULE
TAILLIGHT RELAY
TRANSCEIVER AREA NETWORK BODY CONTROLLER
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VBU
VSA OFF SWITCH
WHT WIRE
WHT/RED WIRE
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Instrument illumination circuit, lx -> TRANSCEIVER AREA NETWORK BODY CONTROLLER
