Honda Odyssey I (2004-2009) aps switch aps switch light Wiring diagram
This page shows the only wiring diagram for the component.aps switch aps switch light, which is found in the car Honda Odyssey I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aps switch aps switch light (1 of 1)
APS FORWARD RELAY (UNDER LEFT SIDE OF DASH)
APS REVERSE RELAY (UNDER LEFT SIDE OF DASH)
APS SWITCH APS SWITCH LIGHT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
DRIVER'S UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) FUSE 15
GRN WIRE
HOT AT ALL TIMES
NAVIGATION SYSTEM
ORG/ WIRE
RED WIRE
TRANSMISSION RANGE SWITCH (ON TRANSAXLE END COVER)
YEL WIRE
Go to component -> Adjustable pedal circuit, touring -> APS SWITCH APS SWITCH LIGHT
