Honda Odyssey I (2004-2009) aps switch aps forward relay Wiring diagram
This page shows the only wiring diagram for the component.aps switch aps forward relay, which is found in the car Honda Odyssey I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aps switch aps forward relay (1 of 1)
+B TPMS
A/C DIODE B (BELOW LEFT SIDE OF DASH)
APS REVERSE RELAY
APS SWITCH APS FORWARD RELAY
BLK WIRE
BLU WIRE
CKP SENSORS
CMP SENSOR PCM
DATA LINK CONNECTOR (DLC)
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
DRL RELAY
ETCS CONTROL RELAY
EX, EX-L, TOURING
EX, TOURING EX-L
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3 FUEL INJECTOR 4
FUEL INJECTOR 5
FUEL INJECTOR 6
FUSE 1
FUSE 12
FUSE 13 (EX, EX-L, TOURING)
FUSE 14 (EX, EX-L, TOURING)
FUSE 15 (TOURING)
FUSE 16 (EX, EX-L, TOURING)
FUSE 17 (TOURING)
FUSE 2
FUSE 23
FUSE 3 (CANADA)
FUSE 4
GRN WIRE
IGNITION COIL RELAY
LEFT POWER SLIDING DOOR CONTROL UNIT
MICU DAY LT
MICU-REAR JUNCTION BOX (BEHIND RIGHT REAR SIDE TRIM PANEL)
MICU-REAR JUNCTION BOX CONTROL UNIT
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (UNDER RIGHT SIDE OF DASH)
PCM
PGM-FI MAIN RELAY 1
PGM-FI SUB- RELAY (LAF)
POWER SEAT CONTROL UNIT
POWER TAILGATE CONTROL UNIT
RADIATOR FAN RELAY
REAR ACCESSORY POWER SOCKET
REAR ACCESSORY POWER SOCKET RELAY
RED WIRE
TPMS CONTROL UNIT
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> APS SWITCH APS FORWARD RELAY
