Car Wiring Diagrams for Instrument illumination circuit for Honda Odyssey I (1994-1999)

8 BULBS A/T GEAR POSITION/ CRUISE CONTROL INDICATOR CIRCUIT ANTI-THEFT SYSTEM (OPTIONAL) ASHTRAY LIGHT BLK WIRE CENTER CONSOLE CENTER POCKET LIGHT CIGARETTE LIGHTER LIGHT CLOCK COMBINATION LIGHT SWITCH CRUISE CONTROL MAIN SWITCH DASH LIGHTS BRIGHTNESS CONTROLLER DIM SIGNAL INPUT DIMMER DRIVER'S VANITY MIRROR LIGHT GAUGE ASSEMBLY GAUGE LIGHTS HAZARD WARNING SWITCH HEAD OFF PARK HEADLIGHT SWITCH HEATER CONTROL PANEL HOT AT ALL TIMES J/C PASSENGER'S VANITY MIRROR LIGHT REAR A/C UNIT SWITCH REAR WINDOW DEFOGGER SWITCH RED WIRE RED/BLK WIRE RED/GRN WIRE SMALL LIGHT FUSE 32 STEREO RADIO/ CASSETTE PLAYER SUNROOF SWITCH (EX MODEL) UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX WHT WIRE
