Honda Odyssey I (1994-1999) Exterior lamps circuit

BLK WIRE BRAKE SWITCH (LEFT SIDE OF I/P) COMBINATION LIGHT SWITCH CRUISE CONTROL SYSTEM FUSE 30 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHT SWITCH HEAD OFF PARK HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM J/C (LEFT SIDE OF FRONT BUMPER) LEFT BRAKE LIGHT FAILURE SENSOR (LEFT REAR OF CARGO AREA) LEFT BRAKE LIGHT/ TAILLIGHT LEFT FRONT PARKING/TURN SIGNAL LIGHT LEFT REAR TURN SIGNAL LIGHT LICENSE PLATE LIGHTS RED/BLK WIRE RED/GRN WIRE RIGHT BRAKE LIGHT FAILURE SENSOR (RIGHT REAR OF CARGO AREA) RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT FRONT PARKING/TURN SIGNAL LIGHT RIGHT REAR TURN SIGNAL LIGHT SMALL LIGHT FUSE 32 STOP LIGHT HORN TO COMBINATION LIGHT SWITCH (DIAGRAM 2 OF 2) TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2) TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 2) UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX WHT/GRN WIRE WHT/YEL WIRE

BACK-UP LIGHTS SYSTEM BLK WIRE COMBINATION LIGHT SWITCH FROM FRONT PARKING/ TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2) FROM REAR TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2) FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 2) GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND HAZARD FUSE 35 HAZARD WARNING SWITCH HOT AT ALL TIMES HOT IN ON OR START BACK-UP METER LIGHTS TURN SIGNALS FUSE 1 IGNITION ILLUMINATION J/C LEFT LEFT TURN INDICATOR LIGHT OFF RED WIRE RED/BLK WIRE RELAY OUT RIGHT RIGHT TURN INDICATOR LIGHT TRAILER LIGHTING CONNECTOR TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD RELAY UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX WHT/GRN WIRE YEL WIRE
