Backup lamps circuit for Honda Odyssey I (1994-1999)
Backup lamps circuit
A/T GEAR POSITION SWITCH (LOWER RIGHT REAR OF ENGINE)
A/T REVERSE DIODE (RIGHT OF STEERING COLUMN)
A/T REVERSE RELAY (RIGHT SIDE OF STEERING COLUMN)
BLK WIRE
GRN/BLK WIRE
HOT IN ON OR START BACK-UP METER LIGHTS TURN SIGNALS FUSE 1
J/C
LEFT BACK-UP LIGHT
RED/WHT WIRE
RIGHT BACK-UP LIGHT
TRAILER LIGHTING CONNECTOR
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
WHT WIRE
YEL WIRE
YEL/WHT WIRE
