Rear wiper/washer circuit for Honda Odyssey (North America) V facelift (2017-2020)
Rear wiper/washer circuit
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 15
FUSE 24
FUSE EA
FUSE/ RELAY HOLDER A
GAUGE CONTROL MODULE
GENERAL JUNCTION
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ DC-DC CONVERTER
OFF
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR (MIDDLE OF TAILGATE)
REAR WIPER/ WASHER SWITCH
RED WIRE
TAN WIRE
UNDER- HOOD FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
WASH
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD/ REAR WINDOW WASHER MOTOR
WIPER/WASHER SWITCH
YEL WIRE
