Tailgate & fuel door release circuit for Honda Odyssey (North America) V facelift (2017-2020)
Tailgate & fuel door release circuit
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUEL FILL DOOR LOCK ACTUATOR
FUEL FILL DOOR LOCK ACTUATOR RELAY
FUEL FILL DOOR SWITCH
FUEL FILL DOOR SWITCH/ FUEL FILL DOOR LOCK ACTUATOR
FUSE 23
FUSE 32
FUSE 5
FUSE/RELAY HOLDER B
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LOCK SWITCH
LT BLU WIRE
OUTER HANDLE SWITCH
PNK WIRE
TAILGATE LATCH SWITCH
TAILGATE LATCH SWITCH/ TAILGATE RELEASE ACTUATOR
TAILGATE OUTER HANDLE SWITCH/LICENSE PLATE LIGHT
TAILGATE RELEASE ACTUATOR
TAILGATE RELEASE ACTUATOR RELAY
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ KEYLESS ACCESS SYSTEM
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
