Power tailgate circuit for Honda Odyssey (North America) V facelift (2017-2020)
Power tailgate circuit (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CLOSER MOTOR
COMPUTER DATA LINES SYSTEM
F-CAN JUNCTION (RIGHT)
FLOOR JUNCTION
FULL LATCH SWITCH
FUSE 16
FUSE 18
FUSE 3
FUSE/ RELAY HOLDER B
GRN WIRE
GRY WIRE
HALF LATCH SWITCH
HOT AT ALL TIMES
HOT W/
LT GRN WIRE
NEUTRAL SWITCH
PNK WIRE
POWER SLIDING DOOR CIRCUIT
POWER TAILGATE CLOSER UNIT (NEAR MIDDLE OF TAILGATE)
POWER TAILGATE CONTROL UNIT
POWER TAILGATE DRIVE UNIT (UPPER LEFT "D" PILLAR)
POWER TAILGATE MOTOR
POWER TAILGATE SENSOR
PPL
RATCHET SWITCH
RED WIRE
SRS UNIT
TAN WIRE
TELEMATICS CONTROL UNIT
UNDER- DASH FUSE/ RELAY BOX
UNDER- HOOD FUSE/ RELAY BOX
WHT WIRE
YEL WIRE
Power tailgate circuit (2 of 2)
B-CAN H B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER POWER TAILGATE SWITCH
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HANDS FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR
KEYLESS BUZZER
LEFT POWER TAILGATE PINCH SENSOR
LOCK SWITCH
LT BLU WIRE
OPTION CONNECTOR (FOR HANDS FREE ACCESS POWER TAILGATE +B BACK UP B)
OPTION CONNECTOR (FOR HANDS FREE ACCESS POWER TAILGATE B)
OUTER HANDLE SWITCH
PNK WIRE
POWER TAILGATE INSIDE SWITCH
PPL
RED WIRE
RIGHT POWER TAILGATE PINCH SENSOR
TAILGATE OUTER HANDLE SWITCH/LICENSE PLATE LIGHT
TAN WIRE
W/ HANDLE FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR
W/O HANDLE FREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR
WHT WIRE
YEL WIRE
