Supplemental restraints circuit for Honda Odyssey (North America) V facelift (2017-2020)

Supplemental restraints circuit (1 of 3)

Odyssey (North America) Honda V facelift (2017-2020): Supplemental restraints circuit (1 of 3)

Get access

BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE CABLE REEL COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG INFLATOR (FIRST) DRIVER'S AIR BAG INFLATOR (SECOND) F-CAN JUNCTION (RIGHT) FIRST FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR FRONT PASSENGER'S AIR BAG INFLATOR FRONT PASSENGER'S KNEE AIR BAG INFLATOR FUSE 1 FUSE 20 FUSE 28 GRN WIRE GRY WIRE HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HOT W/ LEFT FRONT IMPACT SENSOR LT BLU WIRE LT GRN WIRE POWER TAILGATE CONTROL UNIT PPL RED WIRE RIGHT FRONT IMPACT SENSOR SECOND SRS UNIT TELEMATICS CONTROL UNIT UNDER-DASH FUSE/RELAY BOX W/O POWER TAILGATE W/ POWER TAILGATE W/ DISPLAY AUDIO WHT WIRE YEL WIRE

Supplemental restraints circuit (2 of 3)

Odyssey (North America) Honda V facelift (2017-2020): Supplemental restraints circuit (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S KNEE AIR BAG INFLATOR DRIVER'S SEAT BELT TENSIONER DRIVER'S SEAT POSITION SENSOR F-CAN H F-CAN L F-CAN TRANSCEIVER FRONT PASSENGER'S AIR BAG ACTIVE VENT TETHER CUTTER FRONT PASSENGER'S SEAT BELT TENSIONER FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE) FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE) FUSE EA FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GENERAL JUNCTION GRN WIRE GRY WIRE HOT W/ DC-DC LT BLU WIRE LT GRN WIRE PNK WIRE REAR SAFING SENSOR RED WIRE RELAY 1 ENERGIZED SEAT BELT REMINDER INDICATOR SRS INDICATOR W/O SEAT HEATERS W/ SEAT HEATERS WHT WIRE

Supplemental restraints circuit (3 of 3)

Odyssey (North America) Honda V facelift (2017-2020): Supplemental restraints circuit (3 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER'S SEAT BELT BUCKLE SWITCH DRIVER'S SIDE AIR BAG INFLATOR FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FRONT PASSENGER'S SIDE AIR BAG INFLATOR GRN WIRE GRY WIRE LEFT SIDE CURTAIN AIR BAG INFLATOR LEFT SIDE IMPACT SENSOR (FIRST) LEFT SIDE IMPACT SENSOR (SECOND) LEFT SIDE IMPACT SENSOR (THIRD) LT GRN WIRE RED WIRE RIGHT SIDE CURTAIN AIR BAG INFLATOR RIGHT SIDE IMPACT SENSOR (FIRST) RIGHT SIDE IMPACT SENSOR (SECOND) RIGHT SIDE IMPACT SENSOR (THIRD) SRS UNIT W/ SEAT HEATERS W/O SEAT HEATERS YEL WIRE
