Power distribution module circuit for Honda Odyssey (North America) V facelift (2017-2020)
Power distribution module circuit (1 of 2)
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BODY CONTROL MODULE CIRCUIT
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE CONTROLS SYSTEM
FUSE 19
FUSE 3
FUSE 33
FUSE 4
FUSE 5
FUSE HOLDER
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION MODULE (RIGHT KICK PANEL)
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
SMART FET
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Power distribution module circuit (2 of 2)
12 VOLT BATTERY TERMINAL FUSE BOX
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
ENGINE CONTROLS SYSTEM
FUSE 15
FUSE 20
FUSE 21
FUSE AB
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
LT BLU WIRE
ON BATTERY)
PNK WIRE
POWER DISTRIBUTION MODULE (RIGHT KICK PANEL)
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RELAY ENERGIZED
SMART FET
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
