Honda Odyssey (North America) V facelift (2017-2020) w/o auto idle stop system w/ auto idle stop system Wiring diagram
This page shows the only wiring diagram for the component.w/o auto idle stop system w/ auto idle stop system, which is found in the car Honda Odyssey (North America) V facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o auto idle stop system w/ auto idle stop system (1 of 1)
594068 2018-HON-16-01
APP SENSOR A
APP SENSOR A/B
APP SENSOR B
BLK WIRE
BRAKE PEDAL POSITION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 19 28
FUSE 22
FUSE 34
FUSE HOLDER
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM
PNK WIRE
PPL
RED WIRE
SBW SHIFTER CONTROL MODULE
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
