Honda Odyssey (North America) V facelift (2017-2020) hydraulic control unit/ sensor unit Wiring diagram
This page shows the only wiring diagram for the component.hydraulic control unit/ sensor unit, which is found in the car Honda Odyssey (North America) V facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hydraulic control unit/ sensor unit (1 of 1)
ACC COMBINATION SWITCH
APP SENSOR A
APP SENSOR A/B
APP SENSOR B
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
CABLE REEL
CANCEL SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE SWITCH
DISTANCE SWITCH
DUAL SPEED SENSOR
FUSE 1
FUSE 3
FUSE 34
FUSE EA
FUSE EC
FUSE/RELAY HOLDER A
GAUGE CONTROL MODULE
GENERAL JUNCTION
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL UNIT
HEATED STEERING WHEEL SWITCH
HOT W/ DC-DC
HYDRAULIC CONTROL UNIT/ SENSOR UNIT
LKAS SWITCH
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RED/BLU WIRE
RELAY 1 ENERGIZED
RELAY 2 ENERGIZED
RELAY ENERGIZED
RES/+ SWITCH
SET SWITCH
TAN WIRE
TRANSMISSION CONTROL MODULE
UNDER-DASH FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/O AUTO IDLE STOP SWITCH W/ AUTO IDLE STOP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> HYDRAULIC CONTROL UNIT/ SENSOR UNIT
