Honda Odyssey (North America) V facelift (2017-2020) econ switch/snow switch/ idle stop off switch Wiring diagram
This page shows the only wiring diagram for the component.econ switch/snow switch/ idle stop off switch, which is found in the car Honda Odyssey (North America) V facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram econ switch/snow switch/ idle stop off switch (1 of 1)
APPLY SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH
ECON
ECON SWITCH/SNOW SWITCH/ IDLE STOP OFF SWITCH
ELECTRIC PARKING BRAKE SWITCH
FRONT PASSENGER'S DOOR SWITCH
FUSE 23
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IDLE STOP
LEFT SLIDING DOOR SWITCH
LT BLU WIRE
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
RED WIRE
RELEASE SWITCH
RIGHT SLIDING DOOR SWITCH
SNOW
TAILGATE LATCH SWITCH/ TAILGATE RELEASE ACTUATOR
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ POWER TAILGATE
W/O POWER TAILGATE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> ECON SWITCH/SNOW SWITCH/ IDLE STOP OFF SWITCH
