Car Wiring Diagrams for Electronic power steering circuit for Honda Jazz GK facelift (2017-2020)

32 BIT MICROPROCESSOR AUXILIARY UNDER-DASH FUSE BOX BLK WIRE COMPUTER DATA LINES SYSTEM EPS CONTROL UNIT EPS IND F-CAN H F-CAN L F-CAN TRANSCEIVER FAIL SAFE CIRCUIT FORCED TURNING ON CIRCUIT FUSE 1 1 FUSE 27 FUSE 34 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START INDICATOR DRIVE CIRCUIT LT GRN WIRE MOTOR MOTOR ANGLE SENSOR NCA WIRE PNK WIRE PPL PPL PPL RED WIRE STEERING ANGLE SENSOR TORQUE SENSOR UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE
