Honda Jazz GK facelift (2017-2020) computer data lines Wiring diagram
This page shows the only wiring diagram for the component.computer data lines, which is found in the car Honda Jazz GK facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines (1 of 1)
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
FUSE 34
FUSE 37
GPS ANTENNA
GRN WIRE
GRY WIRE
HOT IN ON OR ACC
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MICU
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
RED WIRE
ROOF ANTENNA
SYSTEM
UNDER- DASH FUSE/ RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, w/o navigation w/ display audio (1 of 3) -> COMPUTER DATA LINES
