Honda Jazz GK facelift (2017-2020) audio remote multi- information display switch Wiring diagram
This page shows the only wiring diagram for the component.audio remote multi- information display switch, which is found in the car Honda Jazz GK facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio remote multi- information display switch (1 of 1)
A/C SWITCH
AUDIO REMOTE MULTI- INFORMATION DISPLAY SWITCH
BLK WIRE
CABLE REEL
CRUISE CONTROL COMBINATION SWITCH
CVT
DRIVER'S SEAT HEATER SWITCH
ECON SWITCH
FRONT PASSENGER'S SEAT HEATER SWITCH
GRN WIRE
GRY WIRE
HFT-NAVIGATION VOICE CONTROL SWITCH
LDW/ CBMS OFF SWITCH
LT GRN WIRE
REAR WINDOW DEFOGGER SWITCH
RED WIRE
SELECT/ RESET/ INFORMATION SWITCH
VSA OFF SWITCH
Go to component -> Instrument illumination circuit (2 of 3) -> AUDIO REMOTE MULTI- INFORMATION DISPLAY SWITCH
