Honda Jazz GK facelift (2017-2020) app sensor Wiring diagrams
This page contains all the electrical diagrams for the component. app sensor, in which he is found in the car Honda Jazz GK facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram app sensor (1 of 2)
APP SENSOR
APP SENSOR A
APP SENSOR B
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CLUTCH PEDAL POSITION SWITCH B/D
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
ETCS CONTROL RELAY
FUSE 30
FUSE 4
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM
PGM-FI MAIN RELAY 1
PNK WIRE
PPL
RED WIRE
THROTTLE ACTUATOR
THROTTLE BODY (LEFT REAR OF ENGINE)
THROTTLE OPEN SENSOR
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 2) -> APP SENSOR
Wiring diagram app sensor (2 of 2)
