Honda Jazz GK (2015-2017) under-dash relay holder b rear window wiper motor relay Wiring diagram
This page shows the only wiring diagram for the component.under-dash relay holder b rear window wiper motor relay, which is found in the car Honda Jazz GK (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram under-dash relay holder b rear window wiper motor relay (1 of 1)
A/C SWITCH
AUTOMATIC A/C
BLK WIRE
CABLE REEL
CEILING LIGHT
CLIMATE CONTROL UNIT
COMBINATION LIGHT SWITCH
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CVT
DATA LINK CONNECTOR
DRIVER SEAT HEATER SWITCH
DRIVER'S DOOR LATCH
DRIVER'S DOOR OUTER HANDLE
ECON SWITCH
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S SEAT HEATER SWITCH
FUEL TANK UNIT
GAUGE CONTROL MODULE
HEATER FAN SWITCH
IGNITION KEY SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KEYLESS ACCESS CONTROL UNIT
LEFT POWER MIRROR
M/T
MICU
MOONROOF MOTOR/ CONTROL UNIT
MOONROOF SWITCH
PADDLE SHIFTER (-) (DOWN- -SHIFT SWITCH)
PADDLE SHIFTER+ (UP SHIFT SWITCH)
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK/ UNLOCK)
POWER MIRROR SWITCH
POWER TRANSISTOR
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW WIPER MOTOR RELAY
RIGHT POWER MIRROR
SHIFT LEVER/ SHIFT LOCK SOLENOID
STEERING ANGLE SENSOR
SUNLIGHT SENSOR
TAILGATE RELEASE ACTUATOR RELAY
TPMS SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH RELAY HOLDER A BLOWER MOTOR RELAY
UNDER-DASH RELAY HOLDER B REAR WINDOW WIPER MOTOR RELAY
VSA OFF SWITCH
W/O KEYLESS ACCESS
Go to component -> Ground distribution circuit (2 of 3) -> UNDER-DASH RELAY HOLDER B REAR WINDOW WIPER MOTOR RELAY
