Honda Jazz GK (2015-2017) rear window/ power mirror defogger switch indicator Wiring diagrams
This page contains all the electrical diagrams for the component. rear window/ power mirror defogger switch indicator, in which he is found in the car Honda Jazz GK (2015-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear window/ power mirror defogger switch indicator (1 of 2)
AIR MIX CONTROL MOTOR
AUXILIARY UNDER-DASH FUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
ETCS CONTROL RELAY
FUSE 24
FUSE 3
FUSE 32
FUSE 34
FUSE 4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
HUMIDITY/IN-CAR TEMPERATURE SENSOR
LT BLU WIRE
LT GRN WIRE
MODE CONTROL MOTOR (UPPER RIGHT SIDE OF HVAC UNIT)
ORG/ WIRE
PNK WIRE
PPL
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH INDICATOR
RECIRCULATION CONTROL MOTOR
RED WIRE
TAN WIRE
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH INDICATOR
Wiring diagram rear window/ power mirror defogger switch indicator (2 of 2)
AUXILIARY UNDER-DASH FUSE BOX
AUXILIARY UNDER-HOOD RELAY BOX A
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
FUSE 11
FUSE 13
FUSE 24
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
IND
LEFT POWER MIRROR
LT BLU WIRE
MICU
PNK PNK WIRE
PNK WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH INDICATOR
RIGHT POWER MIRROR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
W/ CLIMATE CONTROL W/O CLIMATE CONTROL
YEL WIRE
Go to component -> Defoggers circuit -> REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH INDICATOR
