Honda Jazz GK (2015-2017) on/off illumination encoder Wiring diagram
This page shows the only wiring diagram for the component.on/off illumination encoder, which is found in the car Honda Jazz GK (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/off illumination encoder (1 of 1)
32 BIT MICROPROCESSOR
AUDIO REMOTE MULTI- INFORMATION DISPLAY SWITCH
B(+)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL COMBINATION SWITCH
DIMMING CIRCUIT
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HFT-NAVIGATION VOICE CONTROL SWITCH
ILLUMINATION CONTROL
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR AMBIENT 1
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR DIAL FACE (WHITE)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR LCD BACKLIGHT (AMBER)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR LCD BACKLIGHT (WHITE)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR POINTER (WHITE)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR S-MATIC BACKLIGHT (WHITE)
INDICATOR DRIVE CIRCUIT
LIGHT CONTROL INDICATOR
LIGHT ON INDICATOR
LT GRN WIRE
ON/OFF ILLUMINATION ENCODER
PNK WIRE
R (+)
RED WIRE
STABILIZE CIRCUIT
TRIP RESET
WHT WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> ON/OFF ILLUMINATION ENCODER
