Honda Jazz GK (2015-2017) from under-dash fuse/relay box 2 of 6) Wiring diagram
This page shows the only wiring diagram for the component.from under-dash fuse/relay box 2 of 6), which is found in the car Honda Jazz GK (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from under-dash fuse/relay box 2 of 6) (1 of 1)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CVT
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
EVAP CANISTER PURGE VALVE
FROM ACCESSORY RELAY (DIAGRAM 6 OF 6)
FROM AUXILIARY UNDER-DASH FUSE BOX (DIAGRAM 1 OF 6)
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX 2 OF 6)
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 6 OF 6)
FRONT ACCESSORY POWER SOCKET
FUSE 1
FUSE 26
FUSE 27
FUSE 28
FUSE 3
FUSE 30
FUSE 32
FUSE 36
FUSE 37
FUSE 38
FUSE 8
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KEYLESS ACCESS CONTROL UNIT
M/T
MAF/ IAT SENSOR
MICU
ORG/ WIRE
PCM
PGM-FI MAIN RELAY 2
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK/UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
SRS UNIT
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STEERING ANGLE SENSOR
TAILGATE RELEASE ACTUATOR RELAY
TAN WIRE
TO ENGINE START/ STOP SWITCH (DIAGRAM 6 OF 6)
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH RELAY HOLDER C
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ KEYLESS ACCESS SYSTEM
W/O IMMOBILIZER W/ IMMOBILIZER
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> FROM UNDER-DASH FUSE/RELAY BOX 2 OF 6)
