Honda Jazz GK (2015-2017) drive circuit indicator Wiring diagram
This page shows the only wiring diagram for the component.drive circuit indicator, which is found in the car Honda Jazz GK (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drive circuit indicator (1 of 1)
32 BIT MICROPROCESSOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT INDICATOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 29
FUSE 32
GAUGE CONTROL MODULE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY SWITCH
IMMOBILIZER INDICATOR
IMMOBILIZER KEYLESS CONTROL UNIT
LT BLU WIRE
MICU
PARKING BRAKE SWITCH
PCM
PNK WIRE
RED WIRE
REGULATOR
SECURITY INDICATOR BLINK CIRCUIT
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Immobilizer circuit -> DRIVE CIRCUIT INDICATOR
