Honda Jazz GK (2015-2017) audio remote/multi-information display switch Wiring diagrams

This page contains all the electrical diagrams for the component. audio remote/multi-information display switch, in which he is found in the car Honda Jazz GK (2015-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram audio remote/multi-information display switch (1 of 3)

Wiring diagram audio remote/multi-information display switch for Honda Jazz GK (2015-2017) (1 of 3)

Get access

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- DISP CHANGE GRN WIRE GRY WIRE HFT-NAVIGATION VOICE CONTROL SWITCH MENU NCA WIRE OFF HOOK SWITCH ON HOOK/ BACK SWITCH PNK WIRE PPL RED WIRE SOURCE TALK SWITCH VOL DOWN VOL UP WHT WIRE XM RECEIVER YEL WIRE

Go to component -> Navigation circuit (3 of 4) -> AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH

Wiring diagram audio remote/multi-information display switch (2 of 3)

Wiring diagram audio remote/multi-information display switch for Honda Jazz GK (2015-2017) (2 of 3)

Get access

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- DISP CHANGE GRN WIRE GRY WIRE HFT-NAVIGATION VOICE CONTROL SWITCH MENU NCA WIRE OFF HOOK SWITCH ON HOOK/ BACK SWITCH PNK WIRE PPL RED WIRE SOURCE TALK SWITCH VOL DOWN VOL UP WHT WIRE XM RECEIVER YEL WIRE

Go to component -> Radio circuit, w/ navigation (3 of 4) -> AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH

Wiring diagram audio remote/multi-information display switch (3 of 3)

Wiring diagram audio remote/multi-information display switch for Honda Jazz GK (2015-2017) (3 of 3)

Get access

32 BIT MICROPROCESSOR AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/ AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- COMPUTER DATA LINES SYSTEM DISP CHANGE F-CAN H F-CAN L F-CAN TRANSCEIVER GAUGE CONTROL MODULE GRN WIRE GRY WIRE HFT-NAVIGATION VOICE CONTROL SWITCH LT BLU WIRE LT GRN WIRE MENU MICROPHONE NAVIGATION SYSTEM NCA WIRE OFF HOOK SWITCH ON HOOK/ BACK SWITCH PARKING BRAKE SWITCH PNK WIRE PPL RED WIRE SOURCE TALK SWITCH USB ADAPTER A VOL DOWN VOL UP WHT WIRE YEL WIRE

Go to component -> Radio circuit, w/o navigation (2 of 2) -> AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH
