Supplemental restraints circuit, electric vehicle for Honda Jazz GG facelift (2011-2014)

Supplemental restraints circuit, electric vehicle (1 of 4)

Jazz Honda GG facelift (2011-2014): Supplemental restraints circuit, electric vehicle (1 of 4)

Get access

BATTERY CONDITION MONITOR MODULE BLK WIRE BLU WIRE BRN WIRE CABLE REEL COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG INFLATOR (IN STEERING WHEEL) FRONT PASSENGER'S AIR BAG INFLATOR FUSE 6 FUSE 8 GRN WIRE HOT IN ON OR START LEFT FRONT IMPACT SENSOR LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT FRONT IMPACT SENSOR SRS UNIT UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Supplemental restraints circuit, electric vehicle (2 of 4)

Jazz Honda GG facelift (2011-2014): Supplemental restraints circuit, electric vehicle (2 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE) FRONT PASSENGER'S WEIGHT SENSOR (FRONT OUTER SIDE) FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE) FRONT PASSENGER'S WEIGHT SENSOR (REAR OUTER SIDE) GRN WIRE GRY WIRE LT GRN WIRE NCA WIRE ODS UNIT OPDS SENSOR RED WIRE WHT WIRE YEL WIRE

Supplemental restraints circuit, electric vehicle (3 of 4)

Jazz Honda GG facelift (2011-2014): Supplemental restraints circuit, electric vehicle (3 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CPU/POWER SUPPLY CIRCUIT CONTROLLER AREA NETWORK CONTROLLER DRIVER'S SEAT BELT SWITCH DRIVER'S SEAT BELT TENSIONER F-CAN H F-CAN L F-CAN TRANSCEIVER FAIL SAFE CIRCUIT FORCED TURNING ON CIRCUIT FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR FRONT PASSENGER'S SEAT BELT SWITCH FUSE 22 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT IN ON OR START INDICATOR DRIVE CIRCUIT LT BLU WIRE PNK WIRE RED WIRE SEAT BELT REMINDER IND SIDE AIR BAG CUT-OFF IND SRS IND UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Supplemental restraints circuit, electric vehicle (4 of 4)

Jazz Honda GG facelift (2011-2014): Supplemental restraints circuit, electric vehicle (4 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER SEAT POSITION SENSOR DRIVER'S SIDE AIR BAG INFLATOR FRONT PASSENGER'S SEAT BELT TENSIONER FRONT PASSENGER'S SIDE AIR BAG INFLATOR GRN WIRE GRY WIRE LEFT "C" PILLAR) LEFT SIDE CURTAIN AIR BAG INFLATOR LEFT SIDE IMPACT SENSOR (FIRST) LEFT SIDE IMPACT SENSOR (SECOND) LT BLU WIRE LT GRN WIRE LT PPL PNK WIRE PNK WIRE PPL RED WIRE RIGHT SIDE CURTAIN AIR BAG INFLATOR RIGHT SIDE IMPACT SENSOR (FIRST) RIGHT SIDE IMPACT SENSOR (SECOND) SRS UNIT WHT WIRE YEL WIRE
