Car Wiring Diagrams for Radio circuit, w/o navigation for Honda Jazz GG facelift (2011-2014)

+B BACKUP AM/FM ANTENNA AM/FM ANTENNA AMPLIFIER ANT B+ ANTENNA LEAD CONNECTOR AUDIO L+ AUDIO R- AUDIO SH AUDIO UNIT AUXILIARY UNDER-DASH FUSE BOX BLK WIRE BLU WIRE BRN WIRE BUS - BUS SH COMPUTER DATA LINES SYSTEM DATA DRIVER'S DOOR SPEAKER FR-L FR-R FRONT PASSENGER'S DOOR SPEAKER FUSE 1 FUSE 14 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON K LINE LEFT REAR DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE MICU MIDDLE OF DASH) NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PPL RADIO SW RED WIRE REMOTE GND REMOTE SIG RF IN RF SH RIGHT REAR DOOR SPEAKER RIGHT TWEETER RR-L RR-R SCTY UNDER-DASH FUSE/RELAY BOX USB ADAPTER CONTROL UNIT USB PORT VBUS VSS OUT W/ SECURITY W/ TWEETERS W/O TWEETERS WHT WIRE YEL WIRE

AUDIO REMOTE SWITCH AUDIO UNIT B-CAN BLK WIRE BLU WIRE BLUTOOTH TRANSCEIVER BRN WIRE CABLE REEL CHANNEL DOWN SWITCH CHANNEL UP SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRN/RED WIRE GRY WIRE HANDSFREE- LINK CONTROL UNIT HFL BACK SWITCH HFL MICROPHONE HFL SWITCH HFL TALK SWITCH HFT ICON HFT MUTE LT GRN WIRE MIC GND MIC SH GND MIC SIG MODE SWITCH ORG/ WIRE PNK WIRE PPL RED/BLK WIRE STEERING WHEEL) STRG SW TELM SIG - TELM SIG SH VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE
