Power seats circuit for Honda Jazz GG facelift (2011-2014)
Power seats circuit
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT- BACK HEATER
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 10
FUSE 40
GRN WIRE
GRY WIRE
HIGH INDICATOR
HOT AT ALL TIMES
HOT IN ON
LOW INDICATOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
