Ground distribution circuit, electric vehicle for Honda Jazz GG facelift (2011-2014)
Ground distribution circuit, electric vehicle (1 of 3)
ACCESSORY POWER SOCKET
ACOUSTIC VEHICLE ALERTING CONTROL UNIT
BATTERY
BLK WIRE
CLIMATE CONTROL UNIT
DATA LINK CONNECTOR (DLC)
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S SEAT HEATER SWITCH
HIGH MOUNT BRAKE LIGHT
INTERACTIVE REMOTE ANTENNA MODULE
INTERACTIVE REMOTE CONTROL UNIT
LEFT BACKUP LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT/ BRAKE LIGHT
MOTOR SHIELD
PARK PIN SWITCH/ SHIFT LOCK SOLENOID/ A/T GEAR POSITION INDICATOR PANEL LIGHT
POWER TRANSISTOR
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT BACKUP LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT/ BRAKE LIGHT
TAILGATE LATCH SWITCH
TPMS CONTROL UNIT
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
YAW RATE ACCELERATION SENSOR
Ground distribution circuit, electric vehicle (2 of 3)
3 MODE SWITCH
A/C CONDENSER FAN MOTOR
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL STROKE SENSOR SHIELD
CABLE REEL
CHARGE INDICATOR
CHARGE LID ACTUATOR
CHARGE LID OPENER SWITCH
CRUISE CONTROL COMBINATION SWITCH
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
ELECTRIC SERVO BRAKE CONTROL UNIT
ELECTRIC WATER PUMP
ELECTRICAL COOLANT HEATER
EPS MOTOR/EPS MOTOR ANGLE SENSOR
FAN CONTROL RELAY
GAUGE CONTROL MODULE
HORN SWITCH
ILLUMINATION LAMP SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KM/H, MPH CHANGE SWITCH
LEFT FRONT PARKING LIGHT/SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT BULB
LT GRN WIRE
M/C RELAY
MANAGEMENT ECU
POWER KEY SWITCH
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
TELEMATICS CONTROL UNIT
UNDER- DASH FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
WINDSHIELD WIPER MOTOR
Ground distribution circuit, electric vehicle (3 of 3)
A/C COMPRESSOR
AUDIO- NAVIGATION UNIT
BATTERY CONDITION MONITOR MODULE
BATTERY FAN RELAY 2
BATTERY MODULE
BLK WIRE
DRIVER'S SEAT POSITION SENSOR
ELECTRIC HEATER WATER PUMP
EPS CONTROL UNIT
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
NCA WIRE
ODS UNIT
POWER CONTROL UNIT
POWER CONTROL UNIT SHIELD
RIGHT FRONT PARKING LIGHT/SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT BULB
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
SECURITY HOOD SWITCH
SRS UNIT
VSA MODULATOR CONTROL UNIT
YEL WIRE
