Immobilizer circuit, electric vehicle for Honda Jazz GG facelift (2011-2014)
Immobilizer circuit, electric vehicle
B-CAN H
B-CAN L
B-CAN TRANCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CPU/POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
F CAN TRANCEIVER
F-CAN H
F-CAN L
FAIL FORCED SAFE TURNING-ON CIRCUIT
FUSE 1
FUSE 22
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IMMOBILIZER INDICATOR
IMMOBILIZER KEYLESS CONTROL UNIT
LT BLU WIRE
LT GRN WIRE
MICU
PARKING BRAKE SWITCH
PNK WIRE
POWER KEY SWITCH
RED WIRE
REGULATOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
