Active bodyworks circuit for Honda Jazz GG facelift (2011-2014)
Active bodyworks circuit
ACOUSTIC VEHICLE ALERTING SPEAKER
ACOUSTIC VEHICLE ALTERING CONTROL UNIT
AUDIO- NAVIGATION UNIT
BLK WIRE
BRAKE PEDAL POSITION SWITCH
COMPUTER DATA LINES SYSTEM
FUSE 22
FUSE 24
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MANAGEMENT ECU
MICU
PPL
RED WIRE
RIGHT END OF DASH)
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
