Honda Jazz GG facelift (2011-2014) multi-fuse 60 Wiring diagrams
This page contains all the electrical diagrams for the component. multi-fuse 60, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
multi-fuse 60 wiring diagram (1 of 3)
A/C
A/C CONDENSER FAN RELAY
A/C SWITCH
A/T
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK PIN SWITCH/ SHIFT LOCK SOLENOID
ACCESSORY
AUDIO REMOTE SWITCH
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BLOWER MOTOR RELAY
CABLE REEL
CONSOLE BOX LIGHT
CRUISE CONTROL
CRUISE CONTROL COMBINATION SWITCH
ETCS CONTROL RELAY
FOG LIGHT SWITCH
FROM FUSE 29 (DIAGRAM 3 OF 5)
FROM FUSE 46 (DIAGRAM 2 OF 5)
FROM TAILLIGHT RELAY (DIAGRAM 3 OF 5)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 29
FUSE 47
FUSE 52
FUSE 53
FUSE 57
GRY WIRE
HANDS- FREE LINK
HAZARD WARNING SWITCH
HEATER-A/C CONTROL PANEL
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING/ SIDE MARKER LIGHT
LEFT LICENSE
MICU
MULTI-FUSE 60
PLATE LIGHT
POWER MIRROR SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW/POWER MIRROR DEFOGGERS SWITCH
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING/ SIDE MARKER LIGHT
RIGHT LICENSE
STEERING WHEEL)
TAILLIGHT RELAY
TO FUSE 52 (DIAGRAM 3 OF 5)
TO FUSE 59 (DIAGRAM 1 OF 5)
TO IGNITION SWITCH (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 5)
VOICE CONTROL SWITCH
VSA OFF SWITCH
W/ NAVIGATION
W/ POWER MIRROR DEFOGGERS
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, except electric vehicle (3 of 5) -> MULTI-FUSE 60
multi-fuse 60 wiring diagram (2 of 3)
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN SWITCH/SHIFT LOCK SOLENOID
ANTENNA INPUT
ATP NP
B-CAN
BATTERY
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELD UNIT
ENGINE ST SIG
ENGINE START SIG
FUSE 1
FUSE 22
FUSE 44
GRN WIRE
GRY/RED WIRE
HOOD SW
HOT IN ON OR START
IMMOB SIG
IMMOBILIZER KEYLESS CONTROL UNIT RECEIVER
IMOCO
K LINE
LT BLU WIRE
LT GRN WIRE
METER
MICU
MULTI-FUSE 60
ON BATTERY)
ORG/ WIRE
PNK WIRE
PPL
RED/WHT WIRE
RELAY GND
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT GROUND
REMOTE STARTING CONTROL UNIT IN-LINE FUSE
REMOTE STARTING SYSTEM ANTENNA
REMOTE STARTING SYSTEM CONNECTOR 1
REMOTE STARTING SYSTEM CONNECTOR 2
REMOTE STARTING/ SECURITY IN-LINE CONNECTOR
S-NET
SCS
SECURITY CONTROL UNIT
SHIFT LOCK
SOLENOID
ST RLY COIL
STARTER
STARTER CUT RELAY
STARTER MOTOR
STARTER SOLENOID
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY BOX CONNECTOR Q
WHT WIRE
WIPER
WIPER/WASHER SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Remote starting circuit (1 of 2) -> MULTI-FUSE 60
multi-fuse 60 wiring diagram (3 of 3)
1 = PULL-IN COIL 2 = HOLD-IN COIL
A/T
BATTERY
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLK/WHT WIRE
CLUTCH INTERLOCK SWITCH
ELD UNIT
FUSE 1
FUSE 44
GRN WIRE
IGNITION SWITCH
LOCK
LT BLU WIRE
LT GRN WIRE
M/T
MICU ATP-NP
MULTI-FUSE 60
ON BATTERY)
ORG/ WIRE
PADDLE SHIFTERS
PNK WIRE
POWER DISTRIBUTION SYSTEM
STARTER
STARTER CUT RELAY
STARTER MOTOR
STARTER SOLENOID
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
W/O
WHT WIRE
Go to component -> Starting circuit -> MULTI-FUSE 60
