Honda Jazz GG facelift (2011-2014) main circuit Wiring diagrams
This page contains all the electrical diagrams for the component. main circuit, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram main circuit (1 of 3)
BLK WIRE
BLU WIRE
BRAKE PEDAL STROKE SENSOR
BRAKE SYSTEM IND
BRAKE WARNING IND
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
ELECTRIC SERVO BRAKE CONTROL UNIT
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FAIL SAFE CIRCUIT
FORCED TURNING OFF CIRCUIT
FORCED TURNING ON CIRCUIT
FUSE 1
FUSE 11
FUSE 22
FUSE 60-1
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR DRIVE
LOWER HYDRAULIC PRESSURE SENSOR
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
MASTER CUT VALVE
MICU
MOTOR
PEDAL FEEL SIMULATOR (LEFT SIDE OF FIREWALL)
PEDAL FORCE SIMULATOR VALVE
PNK LT WIRE
PNK WIRE
PPL
RED WIRE
REGULATOR
RESOLVA
RIGHT END OF DASH)
TANDEM MOTOR CYLINDER (LEFT SIDE OF MOTOR COMPT)
UNDER-DASH FUSE/RELAY BOX
UPPER HYDRAULIC PRESSURE SENSOR
WHT WIRE
YEL WIRE
Go to component -> Advanced hydraulic booster circuit -> MAIN CIRCUIT
Wiring diagram main circuit (2 of 3)
APP SENSOR (LEFT SIDE OF FIREWALL)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL COMBINATION SWITCH
CRUISE CONTROL IND
CRUISE MAIN IND
DIMMING CIRCUIT
DRIVE CIRCUIT
F-CAN
FUSE 1
FUSE 12
FUSE 22
FUSE 24
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HORN SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN
MAIN CIRCUIT
MANAGEMENT ECU
MICU
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
REGULATOR
RESUME
SET-
STABILIZING
SWITCH
TRANSCEIVER/
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
VIO WIRE
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit, electric vehicle (1 of 2) -> MAIN CIRCUIT
Wiring diagram main circuit (3 of 3)
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
EPS CONTROL UNIT (LEFT END OF DASH)
EPS IND
EPS MOTOR (ON STEERING RACK)
EPS MOTOR ANGLE SENSOR (ON EPS MOTOR)
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FAIL SAFE CIRCUIT
FORCED TURNING ON CIRCUIT
FUSE 11
FUSE 2
FUSE 22
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR DRIVE CIRCUIT
LT BLU WIRE
MAIN CIRCUIT
MANAGEMENT ECU
NCA WIRE
ON BATTERY)
PNK WIRE
PPL
RED WIRE
TORQUE SENSOR (REAR OF MOTOR)
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit, electric vehicle -> MAIN CIRCUIT
